Game windows

Window spec (engine)

Anchor

docked right, 24 px from the top, opened with I

Size at 1080p

620 × 912 px (header 112, padding 22)

Cell

48 px; cell = round(48 × uiScale × screenHeight / 1080); phones (touch) clamp cell ≥ 44 and open the window full screen with the bag beside the equipment.

Equipment

12×7 cells: weapons and armour 2×3, helmet/gloves/boots 2×2, belt 2×1, rings/necklace/earring 1×1

Bag

12×5 cells (items keep their footprint)

Quick slots

8 (keys 1 2 3 4 5 6 7 8)

• An item fits a slot only if its type matches (any weapon → main hand; shields → off hand; rings → either ring slot).
• Its stat requirements must be met by the character (shown red in the popup when not).
• A two-handed weapon in the main hand blocks the off hand; equipping one sends the off-hand item to the bag.
• Dropping on a bag area that overlaps exactly one item swaps them; more than one overlap is refused.
• Invalid targets turn the slot background red (slot_invalid), valid ones jade (slot_valid).
• Quick slots 1–8 accept potions and scrolls only (drag in from the bag, drag between slots to swap, drag out to the bag); anything else turns the slot red and is refused.
• Sockets: hovering an equipped weapon or belt shows its sockets over the art. Clicking a socketed gem picks it up and holds it on the cursor (it leaves the socket only when placed; Esc puts it back); dragging a gem onto the item or a socket inserts it (weapon: socket 1 primary, 2–3 weapon supports; belt: socket 1 movement, 2–3 belt supports); a gem already there swaps to the bag.
• Item art is scaled by its painted content, not its square canvas: long weapons stand upright and reach the top and bottom of their 2×3 slot; belts fill 2×1 (apps/wiki/lib/icon-fit.json from tools/build-icon-fit.py).
• Every equipped weapon or belt holds exactly one main gem (socket 1) and up to two supports; a second main gem is refused until the first is taken out. A gem can be dragged out of a socket and into another; a plain click picks it up and holds it.

Contract: packages/game-data/data/ui-windows.json
